SP-17 PUNCH HAMMER INGCO (RH150028) E-21

SP-17 PUNCH HAMMER INGCO (RH150028) E-21

https://www.megatoolmall.com/web/image/product.template/96394/image_1920?unique=d21c706
Part Code: SP‑17
Part Name: Punch Hammer (also called Hammer Piston or Striker)
Tool Model: INGCO RH150028 — 1500 W Rotary Hammer
Diagram Reference: E‑21

🧰 What It Is

The Punch Hammer is a core impact‑producing component inside the rotary hammer’s pneumatic hammer mechanism. In rotary hammers, the hammer piston (sometimes called the punch hammer) moves rapidly back and forth in a cylinder to generate percussive force. This force is what drives the drill bit into hard materials like concrete, brick, and stone.

⚙️ Technical Function

The punch hammer performs several essential roles:

1. Impact Generation

  • Converts the rotary motion from the crankshaft/geartrain into linear hammering motion inside the cylinder.

  • As it moves forward in the cylinder, it compresses air and delivers a powerful impact blow to the mechanism that transmits force to the drill bit.

2. Energy Transfer & Compression

  • Works inside the pneumatic chamber (cylinder) with precise clearance.

  • The air compression ahead of the punch hammer produces the high‑energy impacts that make rotary hammers effective on masonry.

3. Reciprocating Motion

  • A connecting linkage (crank, connecting rod) drives the punch hammer back and forth hundreds or thousands of times per minute.

  • Efficient sealing and fit are needed for maximum impact force.

🛠️ Where It Fits

  • The E‑21 reference indicates its exact position in the exploded parts diagram of the RH150028.

  • It is mounted inside the cylinder (impact chamber), guided by seals and rings, and driven by the crankshaft or connecting rod mechanism.

  • It interfaces with springs, rings, and other internal components that help return it and maintain motion.

₹ 144.20 144.2 INR ₹ 144.20 ₹ 238.00

₹ 140.00 ₹ 238.00
