SP-30 PISTON INGCO (RH150028) D-68

SP-30 PISTON INGCO (RH150028) D-68

https://www.megatoolmall.com/web/image/product.template/96586/image_1920?unique=6e31d77
Part Code: SP‑30
Part Name: Piston
Tool Model: INGCO RH150028 — 1500 W Rotary Hammer
Diagram Reference: D‑68

🧰 What It Is

The piston is one of the core mechanical components inside a rotary hammer’s impact mechanism. It is a precision‑machined metal part that moves back and forth within the cylinder (SP‑22) to generate repeated impact forces that drive the hammer action.

In this tool design, the piston is part of the pneumatic hammering assembly that gives rotary hammers their powerful impact performance on hard materials like concrete and masonry.

⚙️ Technical Function

The piston performs several crucial roles:

1. Impact Generation

  • As the mechanism operates, the piston moves rapidly back and forth inside the cylinder.

  • The motion compresses air in the chamber, creating high‑pressure forces that deliver powerful blows.

2. Energy Transfer

  • The piston converts rotational and linear motion from the drive system into percussive impact energy.

  • This percussive energy is then transmitted to the bit for drilling or chiseling.

3. Guided Motion

  • The piston must have a very precise fit inside the cylinder to seal air pressure and allow efficient movement with minimal friction.

₹ 206.00 206.0 INR ₹ 206.00 ₹ 340.00

₹ 200.00 ₹ 340.00

Not Available For Sale

This combination does not exist.
